VERISURF® MODEL-BASED INSPECTION AND MEASUREMENT SOFTWARE
CAD/CAM CONSULTING SERVICES INC. offers Verisurf software for precision inspection, product assembly, and reverse engineering. Serving customers globally from small, local job shops to large, global manufacturers who need to measure, inspect, and build molds, castings, forgings, dies, stampings, machined, and fabricated parts and tooling assemblies. Verisurf has earned a leadership position in model-based measurement technology by pioneering real-time deviation between manufactured parts and associated CAD models.
WHAT IS VERISURF?
CMM Programming
Object Oriented CMM programming with effcient operation and quality reporting for all brands of CMMs.
Inspection & Analysis
Connect to any manual and portable CMMs for probing and scanning. Inspect to drawings or CAD models with intelligent MBD.
Reverse Engineering
3D scan and probe parts for additive manufacturing and other digitizing tasks. Complete surface and solid modeling with MBD.
CMM Programming
Object Oriented CMM programming with effcient operation and quality reporting for all brands of CMMs.
CMM Programming
Significantly reduce inspection plan setup from hours to minutes with almost no learning curve. You can use with any CMM in a revolutionary click-and-build visual interface.
Open System Freedom:
- Intuitive user experience which is easy to learn, remember, and support.
- Model Based Definition speeds tolerancing, programming, and reporting.
- Create repeatable measurement programs for scanners, manual, portable, or CNC CMMS.
- Measurement device freedom eliminates bottlenecks and lowers costs.
Object Oriented Programming:
- Create programs in Teach Mode or by selecting CAD surfaces, points, and features.
- Intelligent probe management including indexing and racks.
- Dynamic path visualization, simulation, and editing for collision avoidance.
- Support for 3-axis and 5-axis, touch trigger and tactile scanning probe systems.
Connect and Operate CMMs:
- Standard communication protocols and formats include Renishaw UCCserver™, I++ DME, DMIS, and G-Code.
- Optional Universal CMM software to run proprietary controllers from DEA, Leitz, Mitutoyo, Hexagon, Zeiss, Wenzel, LK, Nikon, and Pantec. Optional error mapping to compensate for geometric, volumetric, orientation, positioning, and kinematic errors.
Quality Reporting and Communication:
- Create rich inspection reports with standard or custom formats with your branding.
- Quickly identify quality issues and export or write measurement data to quality management systems for immediate notification.
- Automate first article inspection reports or production inspection with statistical process control and real-time quality dashboards.
Inspection & Analysis
Connect to any manual and portable CMMs for probing and scanning. Inspect to drawings or CAD models with intelligent MBD.
INSPECTION & ANALYSIS SUITE
The Verisurf Inspection & Analysis Suite integrates Verisurf’s CAD, MEASURE and ANALYSIS modules and tackles inspection challenges head-on. Verisurf’s unique, CAD-based architecture can read any file format, interpolate with any common, portable CMM (including arms, trackers, and scanning systems) and has the most flexible reporting capabilities available. Create colorful deviation plots highlighting any tolerance conditions between measured parts and nominal CAD – all in a Windows-standard graphical interface that always delivers a superior user experience. Other features in the Inspection and Analysis suite are:
- Flexible best fit options that reduce scrap and rework.
- Embed stunning color results in your reports.
- Connect to any portable arm, tracker, or scanner.
- Fastest align-inspect-report.
- Measure any 2D or 3D feature type.
- Memorize steps to create reusable plans.
- Full MBD (GD&T) import and annotation.
- Compare as-built to any nominal CAD source.
- Advance best fit increases conformance rates.
Reverse Engineering
3D scan and probe parts for additive manufacturing and other digitizing tasks. Complete surface and solid modeling with MBD.
3D Scanning & Reverse Engineering Suite
The Verisurf 3D Scanning and Reverse Engineering Suite includes CAD, MEASURE, and REVERSE modules and is uniquely suited for any reverse engineering project. The suite features an extensive set of tools for collecting, editing, meshing, and surfacing point cloud and mesh data. Verisurf is fully compatible with Mastercam enabling you to scan, measure, mesh, and model your part and then export to STL for additive manufacturing or CNC program and machine it in one user interface.
Engineering outcomes enabled by Verisurf Reverse solutions include:
- Flexible best fit options that reduce scrap and rework.
- Embed stunning color results in your reports.
- Connect to any portable arm, tracker, or scanner.
- Fastest align-inspect-report.
- Measure any 2D or 3D feature type.
- Memorize steps to create reusable plans.
- Full MBD (GD&T) import and annotation.
- Compare as-built to any nominal CAD source.
- Advance best fit increases conformance rates.
WHY USE VERISURF?
Reverse Engineering
3D scan and probe parts for additive manufacturing and other digitizing tasks. Complete surface and solid modeling with MBD.
We partner with Verisurf because there are many shared values in our two companies. We take pride in our customer relationships, we are a team, and your success is our success.
Verisurf offers:
- A Windows compliant experience.
- Photo realistic rendering.
- Solid and surface modeling.
- Drafting.
- Editing of imported models.
- CAD validation.
- A modular based platform.
- A easy-to-use product with minimal training required and substantial resources.
- Excellent local customer support.
HOW TO GET VERISURF
Reverse Engineering
3D scan and probe parts for additive manufacturing and other digitizing tasks. Complete surface and solid modeling with MBD.
Verisurf is available for purchase through CAD/CAM CONSULTING SERVICES INC. and has a Maintenance program that is available. There is also a learning edition available to test drive the software.
Maintenance benefits include live technical support, annual updates with new features and enhancements, measurement device driver changes and updates, computer operating system software and hardware changes, and CAD/CAM model file format changes. Live training options area available as well as online training geared towards Industry and Education.
